New member from Montana.
Looking to convert my Z55 Autoride to gas shocks(Bilsteins or cheaper) and HD springs, and looking to add something like a 2/2 leveling kit.
I have been researching this for months and still cannot pin it down.
Has someone done this and have a parts list???
Looking for all the parts I need to do it in my driveway.
Truck is a winter rig, only used to get the family to the ski resort and me to work (@ the resort).

You must be logged in to see this image or video!
You must be logged in to see this image or video!


Ordo 87

TYF Newbie
Joined
Mar 24, 2016
Posts
11
Reaction score
6
Location
Alaska
Here is what I did with my 06 Denali...

Moog HD springs
https://www.amazon.com/gp/product/B00498ZR7A/ref=ox_sc_act_title_3?smid=ATVPDKIKX0DER&psc=1
Bilstein 5100 for 2.5" lift
https://www.amazon.com/gp/product/B01AX9FSCW/ref=ox_sc_act_title_2?smid=A24CSNU1LOOPXE&psc=1https://www.amazon.com/gp/product/B01AX9FSCW/ref=ox_sc_act_title_2?smid=A24CSNU1LOOPXE&psc=1
Supreme Suspension 0-3" level/lift
https://www.amazon.com/gp/product/B01MUI22EA/ref=ox_sc_act_title_1?smid=AA4645M9FHJV2&psc=1

Here's what I wish I did, which btw, is not much more expensive but better for cold weather... (I live in AK)

Rancho RS9000xl 9 position select (Front)
https://www.amazon.com/Rancho-RS999...-442-4-2-2475-104-&vehicleName=2006+GMC+Yukon

Rancho RS9000xl 9 position select (Rear)
https://www.amazon.com/Rancho-RS999...442-4-2-2475-104-3&vehicleName=2006+GMC+Yukon

Cognito upper control arms (to maintain better geometry and saving your ball joints)
https://cognitomotorsports.com/cogn...-for-99-06-silverado-sierra-1500-2wd-4wd.html

I don't know if I would recommend this, but I did a 6" Rough Country lift...the bump stops have clearance problems so my ride isn't that good but it saves my tires which makes a big difference to me (33" Toyos arent cheap) The shocks and springs that come in this kit are poop, and like I said, there is clearance problems with the stock bump stops...but it's a cheap lift kit.
https://www.roughcountry.com/gm-suspension-lift-kit-280n2.html


Ordo 87

TYF Newbie
Joined
Mar 24, 2016
Posts
11
Reaction score
6
Location
Alaska
Only for two reasons: 1. you simply want new ones....2. the stock ones are damaged/need to be R2.
Otherwise no, you can use the stock ones.
I used a 1.5" Supreme Suspension lift block under mine when I did it and it was too high; a 1" lift block would put you around 2-2.5" lift in the rear.
Careful pushing those lift keys down too far; the steering gets very squirrelly and you wear out the outer tread on your tires very quickly.
