Fox coilovers with xineering magnaride delete kit

Discussion in 'Lifted Supension - Z71 & 4x4' started by olyelr, Sep 14, 2019.

  1. Billhicks1984

    Billhicks1984 Member

    Posts:
    53
    Likes Received:
    15
    Joined:
    Jul 27, 2016
    Name:
    N/A
  2. crazycrew

    crazycrew Full Access Member

    Age:
    38
    Posts:
    1,297
    Likes Received:
    825
    Joined:
    Mar 11, 2010
    Location:
    Vacherie, LA
    Name:
    Brooks
    Since we are lowered, I think I'm gonna go with the atomic fab and performance coil over brackets and stock height viking coil overs. It says 08-14 but I'm almost positive it'll work for me. I'll be sure before ordering, lol

    [​IMG]

    Sent from my SM-G955U using Tapatalk

  3. TheEngineer

    TheEngineer TYF Newbie

    Posts:
    23
    Likes Received:
    7
    Joined:
    Aug 7, 2018
    Location:
    Central, FL
    Name:
    Max
    To Summarize:
    15+ Suburban, Tahoe, Yukon, YukonXL

    Fox Part Numbers

    Front Coilover: 985-02-018
    Rear shocks: 980-24-660

    Billhicks1984 likes this.
  4. Christian915

    Christian915 TYF Newbie

    Posts:
    5
    Likes Received:
    1
    Joined:
    Jul 15, 2017
    Name:
    TinaTahoe
    where you able to lower down the coilovers?

  5. olyelr

    olyelr Full Access Member

    Age:
    38
    Posts:
    422
    Likes Received:
    146
    Joined:
    Mar 19, 2011
    Location:
    Elk Rapids, MI
    Name:
    Brandon
    Nope, not yet. Still waiting on a new nut from Fox. Its been a clusterfawk to say the least, but all because of my own stupidity.

    Plan is to get the new nut, go to a place that has an actual strut machine, fully unload the coil pressure (get it away from the nut), carefully cut the stripped nut off the shock body, put the new nut on in a lower position and be done with it.

    Shitty part is, I have not been able to figure out exactly how much to lower the nut for a desired right height. Nobody can seem to give me a rough idea. So I guess it will be a trial and error thing... lower it a little, reinstall shock/tires and see what it looks like... then repeat if necessary till I find the desired ride height.

  6. Oh Kee Pah

    Oh Kee Pah TYF Newbie

    Posts:
    24
    Likes Received:
    12
    Joined:
    Mar 26, 2019
    Location:
    MAINE
    Name:
    Robert

    Shitty part is, I have not been able to figure out exactly how much to lower the nut for a desired right height. Nobody can seem to give me a rough idea. So I guess it will be a trial and error thing... lower it a little, reinstall shock/tires and see what it looks like... then repeat if necessary till I find the desired ride height.[/QUOTE]




    I think you're making a good decision going to the wall mounted coil compressor. When I spoke with Fox months ago they told me that's what needed to be done. That the threads could be ruined if trying to use a wrench or other methods.

    If you are looking for the 1.5-2" Front ride height increase, I suggest starting at 1/4" or 0.25" decrease on the Fox threads. ALSO, mark the thread where you started (stock/out of the box) and then the thread where you end. If the Fox shocks act similar to mine, I think the 1/4" will get you to an actual decrease of around 1/2" or 0.5" decrease to stock, maybe more. Hopefully you'll end up somewhere around 1.5 - 1.75" ride height increase from original measurements.

    There is also a "Ride Height Trim Procedure" that goes along with any GM Suspension work. As per my friends at Xineering.com (manufacturers of GM Shock Sims):

    "It is a function used by the GM Dealerships scan tool to re-calibrate the suspension control module for any changes in ride height or ride height sensors to set the 'zero' ride height position of the vehicle.
    It reads the ride height sensor voltages, stores them in memory, and sets them as the normal ride height position

    The Suspension Control Module (SCM) is calibrated from the factory for its stock ride based on the ride height sensor voltages. This is the stock 'zero' suspension travel position for the magneride system.

    As the vehicle drives (moves up/down, side to side) an algorithm determines how much electrical current (mA) to send to each magneride shock in order to maintain a smooth ride. The amount of current sent to a shock is proportional to how hard or soft the control module wants the shock to dampen.
    If the ride height of the vehicle changes, due to a shock or spring replacement
    OR If any ride height sensors have been replaced
    A ride height trim calibration procedure is necessary, to re-zero the system."

    Apologies for the slow response - family vacation, headaches and work catch up - Disney. Need I say more?


  7. olyelr

    olyelr Full Access Member

    Age:
    38
    Posts:
    422
    Likes Received:
    146
    Joined:
    Mar 19, 2011
    Location:
    Elk Rapids, MI
    Name:
    Brandon


    I think you're making a good decision going to the wall mounted coil compressor. When I spoke with Fox months ago they told me that's what needed to be done. That the threads could be ruined if trying to use a wrench or other methods.

    If you are looking for the 1.5-2" Front ride height increase, I suggest starting at 1/4" or 0.25" decrease on the Fox threads. ALSO, mark the thread where you started (stock/out of the box) and then the thread where you end. If the Fox shocks act similar to mine, I think the 1/4" will get you to an actual decrease of around 1/2" or 0.5" decrease to stock, maybe more. Hopefully you'll end up somewhere around 1.5 - 1.75" ride height increase from original measurements.

    There is also a "Ride Height Trim Procedure" that goes along with any GM Suspension work. As per my friends at Xineering.com (manufacturers of GM Shock Sims):

    "It is a function used by the GM Dealerships scan tool to re-calibrate the suspension control module for any changes in ride height or ride height sensors to set the 'zero' ride height position of the vehicle.
    It reads the ride height sensor voltages, stores them in memory, and sets them as the normal ride height position

    The Suspension Control Module (SCM) is calibrated from the factory for its stock ride based on the ride height sensor voltages. This is the stock 'zero' suspension travel position for the magneride system.

    As the vehicle drives (moves up/down, side to side) an algorithm determines how much electrical current (mA) to send to each magneride shock in order to maintain a smooth ride. The amount of current sent to a shock is proportional to how hard or soft the control module wants the shock to dampen.
    If the ride height of the vehicle changes, due to a shock or spring replacement
    OR If any ride height sensors have been replaced
    A ride height trim calibration procedure is necessary, to re-zero the system."

    Apologies for the slow response - family vacation, headaches and work catch up - Disney. Need I say more?

    [/QUOTE]

    Thanks for the reply! Hope vacation was fun!!!

    So your saying maybe drop the nut down a quarter inch, and start there?

  8. olyelr

    olyelr Full Access Member

    Age:
    38
    Posts:
    422
    Likes Received:
    146
    Joined:
    Mar 19, 2011
    Location:
    Elk Rapids, MI
    Name:
    Brandon
    Im not so sure I need to mess with right height sensors at all. The front is deleted, and the rear I would prefer to leave at the stock height.
