TPMS Relearn 2015+

Discussion in 'Tech Info' started by Doubeleive, Oct 15, 2019.

Car Parts
  1. Doubeleive

    Doubeleive Supporting Member

    Posts:
    8,785
    Likes Received:
    7,830
    Joined:
    Nov 7, 2017
    Location:
    Stockton, Ca.
    Name:
    Wes
    this should work on all 2015+ suv and 2014+ pickups
    browse thru the DIC info screen until you get to the tpms display, then press and hold the select button (checkmark button) for about 5 seconds, the horn will honk twice and the display will say tpms relearn, then use your tpms tool starting at the front left drivers wheel use your tool to read the sensor, once the horn honks once proceed to the next wheel in a clockwise direction, as the next sensor is read the horn will honk once again when the last wheel is read the horn will honk twice and you are finished.

  2. gat0r

    gat0r Full Access Member

    Posts:
    1,320
    Likes Received:
    605
    Joined:
    Dec 11, 2015
    Location:
    DFW
    Name:
    Jay
    works good unless you have a questionable sensor ;)

  3. hcvone

    hcvone Full Access Member

    Posts:
    154
    Likes Received:
    129
    Joined:
    May 30, 2019
    Location:
    Huntingdon Valley, PA - Town of Webb, NY
    Name:
    Carl
    Still the same in 2019 on the Tahoe, all my other cars and SUV's relearn themselves without the need of the tool

  4. Bob2C

    Bob2C Full Access Member

    Posts:
    192
    Likes Received:
    134
    Joined:
    Jun 11, 2019
    Location:
    Northern VA
    Name:
    Robert
    Yeah. I just done get why GM has a manual relearn process. Never had to do this with any other car. Crazy


    Sent from my iPhone using Tapatalk

  5. Cantrepeat

    Cantrepeat Member

    Posts:
    76
    Likes Received:
    61
    Joined:
    Nov 29, 2019
    Location:
    Sweet Home Alabama
    Name:
    Tim
    What's the TPMS tool you speak of?

  6. wjburken

    wjburken Supporting Member

    Posts:
    2,394
    Likes Received:
    3,728
    Joined:
    Dec 26, 2017
    Location:
    Eastern Iowa
    Name:
    Wade
  7. cs15dah

    cs15dah TYF Newbie

    Posts:
    7
    Likes Received:
    1
    Joined:
    Mar 16, 2019
    Name:
    cs15dah
    The relearn procedure isn’t necessarily about the vehicle relearning the TPMS sensors, but rather the vehicle understanding which TPMS sensor is at which corner of the vehicle. When you scroll to the TPMS page in your instrument cluster, and you see the diagram of your vehicle, and the corresponding pressures, the TPMS relearn is how the vehicle tells you which-tire is what-PSI.

    if you rotate your own tires, learning how to perform the relearn sequence is important. Heck, even if you paid to have your tires rotated, knowing how to do it yourself may save you a trip back to the servicing tire shop, in the event that the shop forgets to complete the job in full and relearn your sensors. ;)

    You didn’t have to do this in the past with the first generation of TPMS technology because vehicle instrument clusters just simply showed a low tire pressure icon when low pressure was detected. But not which specific tire was low. The only time you had to relearn a sensor was when you replaced one or more of them.

  8. hcvone

    hcvone Full Access Member

    Posts:
    154
    Likes Received:
    129
    Joined:
    May 30, 2019
    Location:
    Huntingdon Valley, PA - Town of Webb, NY
    Name:
    Carl
    I have a Bartec 300 , got it on ebay for a 1/4 of the price new and it was never used

  9. Da90

    Da90 Full Access Member

    Posts:
    680
    Likes Received:
    678
    Joined:
    Jun 16, 2009
    Location:
    Tulsa, OK
    Name:
    Dustin
  10. BlaineBug

    BlaineBug Full Access Member

    Posts:
    87
    Likes Received:
    18
    Joined:
    Dec 29, 2019
    Location:
    Indiana
    Name:
    Blaine
    Most cars don't show you which corner the TPMS pressure is at. That's why you must relearn the position with these. When you do a tire rotation you don't have to relearn but then your locations will be skewed.
