Kbuskill's 2008 Burb LTZ "MOD" Thread

Disclaimer: Links on this page pointing to Amazon, eBay and other sites may include affiliate code. If you click them and make a purchase, we may earn a small commission.

89Suburban

Bull in the china shop
Supporting Member
Joined
Jan 10, 2013
Posts
12,853
Reaction score
35,235
Location
SE PA
Yes... it is cast aluminum, as opposed to the plastic Y-connector found on the factory hose assembly... that's why I am replacing it as well, to get rid of all the plastic fittings.

That's pretty sweet I didn't know they made them.


Rocket Man

Mark
Supporting Member
Joined
Dec 25, 2014
Posts
25,961
Reaction score
50,621
Location
Oregon
Received my Gruven heater core T-connectors and Dorman Y-connector today...

rps20190628_145555_677-jpg.225748

rps20190628_145626_706-jpg.225749

rps20190628_145703_107-jpg.225750

Its gonna be next weekend before I can get them installed.
Even Dorman knows to use spring clamps. I can’t believe Gruven sends those crappy screw clamps for the price they charge plus the one end of their tee doesn’t have a barb. I expected more from them.

OP
OP
kbuskill

kbuskill

***CAUTION*** I do my own stunts!
Joined
Mar 11, 2017
Posts
5,213
Reaction score
8,068
Location
NE. FL.
Well 3 of my 4 new wheels and tires arrived today... Fed Ex says the 4th will be delivered tomorrow.... crazy, but whatever.

I decided I didn't really like having a "brushed aluminum" looking center cap on a chrome rim so I decided to see if the factory Bowtie center caps would fit the new wheels.... sadly they wouldn't just pop in because they were ever so slightly bigger in diameter.

So the modifications started...

Center cap from new wheels... "Brushed" looking...

I removed the metal cover from the plastic underneath by prying the tabs back...

I discovered that the Bowtie is removable on the aftermarket Bowtie center caps I bought when I lost one of the originals... not sure if the originals are the same or not...

I had to remove all the tabs seen here from the rear of the Bowtie caps...

I then drilled a hole in the center and ran I screw through the center...

Continued in next post...

OP
OP
kbuskill

kbuskill

***CAUTION*** I do my own stunts!
Joined
Mar 11, 2017
Posts
5,213
Reaction score
8,068
Location
NE. FL.
I then drilled two holes on either side of the center hole of the Heavy Hitters center cap to allow room for the two pins that hold the Bowtie to the center cap and placed it on the back side of the Bowtie cap...

Then I placed a washer over the hole and secured it all together with a nylon lock nut to clamp everything together...

This is the Bowtie cap from the front. You can see where I counter sunk the screw head slightly...

Then I reinstalled the Bowtie to hide the screw...

Then I installed the new custom one off CHROME center caps onto the new wheels to see how they looked and fit...

Unfortunately it was after dark by the time I finished so the pics didn't turn out the greatest but I will get better pics in the day time...

Continued in the next post...

OP
OP
kbuskill

kbuskill

***CAUTION*** I do my own stunts!
Joined
Mar 11, 2017
Posts
5,213
Reaction score
8,068
Location
NE. FL.
Here is a pic of the wheel sitting in front of the truck before I modified the center caps...
I hadn't even fully unwrapped them in this pic... lol

And here is a couple of the crappy, after dark, pics of the new modified center caps...


Like I said... not the best pics but I think they turned out fantastic.

I realize that 99% of the population will never even notice that the center caps are different from what came on these wheels...

BUT...

For the 1% of us gear heads, I think this is a cool mod because I know if I saw these center caps I would automatically associate them with factory/OEM wheels... and it would drive me nuts trying to figure out what vehicle the wheels came on from the factory.... LMAO


Sam Harris

Supporting Member
Joined
Sep 26, 2018
Posts
7,375
Reaction score
14,716
Location
Texas
Here is a pic of the wheel sitting in front of the truck before I modified the center caps...
View attachment 226014
I hadn't even fully unwrapped them in this pic... lol

And here is a couple of the crappy, after dark, pics of the new modified center caps...
View attachment 226015

View attachment 226016

Like I said... not the best pics but I think they turned out fantastic.

I realize that 99% of the population will never even notice that the center caps are different from what came on these wheels...

BUT...

For the 1% of us gear heads, I think this is a cool mod because I know if I saw these center caps I would automatically associate them with factory/OEM wheels... and it would drive me nuts trying to figure out what vehicle the wheels came on from the factory.... LMAO
That’s awesome. Waiting for the daylight pics.. [emoji16][emoji106]
