Tonyrodz
Resident Resident
I want one!!Did the ol' NBS to NNBS leather shifter swap
What did you do to your NBS GMT800 Tahoe/Yukon Today?
- Thread starter vwbeaner
- Start date
Disclaimer: Links on this page pointing to Amazon, eBay and other sites may include affiliate code. If you click them and make a purchase, we may earn a small commission.
Get it!
Tonyrodz
Resident Resident
I'm a broke mofo!
HiHoeSilver
Away!
I think i asked this before to no avail... I have seen a few listed that say "for 6l80e vehicles only" or something... Is there really a difference?
Tonyrodz
Resident Resident
Maybe for the tow/haul button.
HiHoeSilver
Away!
So are there 2 versions? We have guys here with nnbs levers on 4l60's, right?
Tonyrodz
Resident Resident
I was just trying to give my best guess. Only thing I could think off that could have some affect where the transmission is concerned.
HiHoeSilver
Away!
Yeah, I just didn't even think there could be a difference. The button just turns the computer to a different tune. It's just a momentary switch. I wondered if the way it hooked to the column could be different, like there's an extra position or something...
There's a + - button that's for manual shifting of the 6l80 that we just don't use. The plug is different since there's 2 black wires for that button plus 2 white wires for the tow/haul button, so it's a 4-wire plug. Either cut the plug off the old shifter and wire it to the white wires of the new shifter so it plugs right into the truck or wire the white wires direct with no plug. The black wires don't get used. And the + - button has a circuit in the shifter with resistors in it so the 6l80 knows if you're hitting the + or - so if you want to use that button for something else you'll have to open up the shifter and mod it.
05Single
afraid of the dark
- Joined
- Feb 26, 2015
- Posts
- 8,183
- Reaction score
- 11,448
The nnbs base model one only has 2 wires like the nbs so trial and error is the same since mark already figured out the 4 wire plug lol.
I call it the base model cause I figure the +/- version is an upgrade option.
I actually have 2, one with +/- one without. But not an esky one. Either way the nnbs look and feel better than the nbs imo
Edit: my wires were black , blue, pink , and purple . I hooked up the black and blue for the tow haul
I call it the base model cause I figure the +/- version is an upgrade option.
I actually have 2, one with +/- one without. But not an esky one. Either way the nnbs look and feel better than the nbs imo
Edit: my wires were black , blue, pink , and purple . I hooked up the black and blue for the tow haul
Last edited:
