There have been plenty of people asking for the part numbers to do this upgrade.

Parts

22756664 - ESV Bumper Cover
22756666 - Non-ESV Bumper Cover

22756668 - Hitch Cover
22756954 - Bracket for Hitch Cover
11612235 - Stud to hold Hitch Cover on x2
11612236 - Nut to Hold Hitch Cover on x2

You must get this hitch cover, Denali or any other Escalade covers WILL NOT work. You will also need 8 rivets (or bolts) to hold the hitch cover bracket to the bumper. You can buy them at GM or just have your body shop do it. I only used 2 and it seems to be fine.


22756941 - Exhaust Sleeve
22756942 - Exhaust Sleeve
11570498 - Bolt to hold Sleeve to bumper x8


15853597 - Pad
15853598 - Chrome trim on the pad

If you already have a Denali or Escalade with the chrome trimmed step pad, you can use yours.






Nathan

Last edited:

THE YETI

Director of Operations
Supporting Member
Joined
Apr 29, 2009
Posts
25,494
Reaction score
10,044
Location
South FL
Sticky this.. STAT!

:Handshake:


Also, the actual schematic calls for 8 rivets. Although 2 will work, we did all 8 and include all 8 in the packing.


07Burb

GM fan for life
Staff member
Administrator
Supporting Member
Joined
Jan 3, 2011
Posts
49,908
Reaction score
15,449
Thread stickied!! Nice!


soulsea

Staff member
Administrator
Supporting Member
Joined
Feb 19, 2011
Posts
11,667
Reaction score
-93,765,693
Location
Bar
You'll also need some condoms for all the sex.


Juniorss

Full Access Member
Joined
Mar 15, 2010
Posts
340
Reaction score
9
Location
Long Island, NY
Thanks for all the part number Nathan. It looks like I can get it all for around 1200 through the shop I used to work at here on the Island. Not cheap but it looks soo good.. Decisions decisions..


07Burb

GM fan for life
Staff member
Administrator
Supporting Member
Joined
Jan 3, 2011
Posts
49,908
Reaction score
15,449
Damn it you just made this WAY to easy to get :/ nice write up Nathan!

It was also easy before :hands: Robbie posted similar info a while back :)
