Here's the story. I've got a buddy who just acquired an 07 Tahoe. It's got high miles but has been meticulously maintained (he's got all the records on it) and is super clean.

With that said, there are some bits that need some attention. One of those things being the emergency brakes it is not working as well as he'd like for them to and he uses them a lot when loading and loading his boat at the boat ramp. The good news is he's very mechanically inclined but he's new to the GMT900 world as he's spent the last several years in square body suburbans. He's had the rear rotors off to take a look at everything back there. It all looks to be in good shape. So he just cleaned everything up real good and adjusted what he could. It helped a little but is still not 100% and there is no adjustment in the cable whatsoever.

Anyone out there with some tips and tricks that I can pass along to him? He's a member on the forum here but has very little time in his day for forums right now.


Yuko04

"SquareBODluvr"
Joined
Aug 13, 2010
Posts
6,819
Reaction score
1,608
Location
MN
Here's the story. I've got a buddy who just acquired an 07 Tahoe. It's got high miles but has been meticulously maintained (he's got all the records on it) and is super clean.

With that said, there are some bits that need some attention. One of those things being the emergency brakes it is not working as well as he'd like for them to and he uses them a lot when loading and loading his boat at the boat ramp. The good news is he's very mechanically inclined but he's new to the GMT900 world as he's spent the last several years in square body suburbans. He's had the rear rotors off to take a look at everything back there. It all looks to be in good shape. So he just cleaned everything up real good and adjusted what he could. It helped a little but is still not 100% and there is no adjustment in the cable whatsoever.

Anyone out there with some tips and tricks that I can pass along to him? He's a member on the forum here but has very little time in his day for forums right now.
Those come with 3 different cable lengths if I remember correctly. Also....2 different style of emergency brake shoe sizes. If he has the wrong cable which is longer. They will not compress inside of the rear rotor tight enough to hold. If the emergency brake shoe is the wrong thicknes (too small) even with emergency brake pedal pressed all the way down, will not hold like it should. I ran into this problem on my 04. Several trips back and forth to parts house. On the 07, It is easier to give parts guy VIN# especially dealing with brakes.

"Square Headed and Dually noted"!


89Suburban

Bull in the china shop
Supporting Member
Joined
Jan 10, 2013
Posts
12,851
Reaction score
35,223
Location
SE PA
Thank you Jacob for the thread and any and all responders. I am assuming the cables are the factory ones. This truck has 300K on it. Yesterday I replaced all the rotors and pads. I order new parking brake shoes but they gave me standard drum brake shoes instead of the disk brake top hat shoes. But upon inspection of the old parking brake shoes they seemed to have plenty of meat on them. And I snugged them up so the rotor would slide on with slight resistance. It just seems like the shoes aren't holding and slipping. It holds ok forward but terrible in reverse. And that is a problem because I launch a boat just about every day of the year.

Jonas thanks for the info and I will use your advice to get the correct shoes to install. Doesn't help much when you have retards to deal with at the parts counter either...


89Suburban

Bull in the china shop
Supporting Member
Joined
Jan 10, 2013
Posts
12,851
Reaction score
35,223
Location
SE PA
Ok I got this fixed. Ordered new parking brake linings. Found that the driver's side rear wheel seal has a weep in it and it contaminated the brake lining so it wasn't grabbing. Cleaned it up real good in there. All good now except now I got to keep an eye on it and eventually replace wheel seals. Which I am no stranger to doing but I never messed with a Gov-Loc rear before so I'll have to study up on pulling the axle shafts on that setup.

OP
OP
07Burb

07Burb

GM fan for life
Staff member
Administrator
Supporting Member
Joined
Jan 3, 2011
Posts
49,908
Reaction score
15,449
Ok I got this fixed. Ordered new parking brake linings. Found that the driver's side rear wheel seal has a weep in it and it contaminated the brake lining so it wasn't grabbing. Cleaned it up real good in there. All good now except now I got to keep an eye on it and eventually replace wheel seals. Which I am no stranger to doing but I never messed with a Gov-Loc rear before so I'll have to study up on pulling the axle shafts on that setup.
Nice job, buddy :)


swathdiver

Full Access Member
Joined
May 18, 2017
Posts
19,100
Reaction score
25,031
Location
Treasure Coast, Florida
The adjustment is in the mechanism inside the cab. Most common issues are stretched out cable(s). The weather is finally getting cool, hopefully I can do mine this weekend and that all the parts I ordered months ago are correct!


89Suburban

Bull in the china shop
Supporting Member
Joined
Jan 10, 2013
Posts
12,851
Reaction score
35,223
Location
SE PA
Here's the story. I've got a buddy who just acquired an 07 Tahoe. It's got high miles but has been meticulously maintained (he's got all the records on it) and is super clean.

With that said, there are some bits that need some attention. One of those things being the emergency brakes it is not working as well as he'd like for them to and he uses them a lot when loading and loading his boat at the boat ramp. The good news is he's very mechanically inclined but he's new to the GMT900 world as he's spent the last several years in square body suburbans. He's had the rear rotors off to take a look at everything back there. It all looks to be in good shape. So he just cleaned everything up real good and adjusted what he could. It helped a little but is still not 100% and there is no adjustment in the cable whatsoever.

Anyone out there with some tips and tricks that I can pass along to him? He's a member on the forum here but has very little time in his day for forums right now.
:hands:
